dmXLAN NodeHD 24

The dmXLAN NodeHD 24 DMX / Ethernet Node featuring 24 fully isolated modular DMX ports, dual Gigabit ethernet ports and an integrated user interface with display.

It features 24 bi-directional, optically isolated DMX ports across two modules, configurable as DMX/RDM outputs and inputs or as Serial-LED outputs. Two Gigabit EtherCON ports are located on the rear panel of the unit.

Two of the four module ports can be occupied by either an EtherCON module or an RJ45 module, with each module providing 12 DMX outputs per module. These modules can be fitted either in the front or the rear of the unit.

The dmXLAN NodeHD 24 is fully compatible with the free dmXLAN software. This allows, as an example merging into HTP or Priority, as well as a softpatch function. Device parameters can also be operated remotely from here.

Find a distributor near you
View manual

Need firmware, software or downloads?

Head to our support section for manuals, firmware, software tools (including version history), and help with troubleshooting.

Features

  • 2x 12 DMX ports combined in physical connector modules
  • RDM compatible with RDM proxy support (input and output)
  • Supports sACN, Art-Net, Shownet, Vision.net & RTTrPL
  • Supports pixel LED string protocols WS2812, WS2813, UCS1903, and SK6822, providing control for up to 12,240 serial LEDs from a single unit
  • Remote (offline) programming and monitoring and fixture parameter override using dmXLAN v4 or Fixture Tester
  • DMX Redundancy, loop the DMX back to another NodeHD or NodeGBx output for failover backup
  • DMX Output normal, HTP, Priority merging, Softpatch (channel by channel), programmable merging with DMX channel control
  • Four configurable GPI contact closures
  • Support for WYSIWYG, Depence, Capture, Vision and other visualization software
  • EtherCON modules with 3 EtherCONs using the AES-72-1M pinout providing 4 DMX ports combined in a single connector. Polarity of pins 4 & 5 can be reversed by a jumper on the module itself
  • RJ45 modules with 12 RJ45 connectors using the standard ESTA pinout providing a single DMX port per connector
  • Local control via color display with rotary encoder and pushbutton selector
